Leírás
| Parameter | VENTS 100 X | VENTS 100 XT | VENTS 100 XTH | VENTS 100 XV | VENTS 100 XVT | VENTS 100 X L | VENTS 100 XV L | VENTS 100 X K | VENTS 100 X K L | VENTS 100 XTH K L | Measurement unit |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Voltage | 220-240 | V | |||||||||
| Frequency | 50/60 | Hz | |||||||||
| Power consumption | 14 | W | |||||||||
| Air capacity | 89 | m³/h | |||||||||
| Current | 0.085 | A | |||||||||
| RPM | 2300 | min-1 | |||||||||
| Sound pressure level at 3 m | 33 | dBА | |||||||||
| Weight | 0.61 | kg | |||||||||
| Spigot size | 100 | mm | |||||||||
| Engine Type | 220-240V / 50-60Hz | - | |||||||||
| Duct diameter | 100 | mm | |||||||||
| Design | axial | - | |||||||||
| IP Code | IP 24 | - | |||||||||
| Type | exhaust | - | |||||||||
| Mounting | wall mounting, ceiling mounting | - | |||||||||
| Parameter | Value | Measurement unit |
|---|---|---|
| Ø D | 100 | mm |
| B | 152 | mm |
| H | 120 | mm |
| L | 125 | mm |
| L1 | 30 | mm |
