Leírás
| Parameter | VENTS 100 X1 | VENTS 100 X1T | VENTS 100 X1TH | VENTS 100 X1V | VENTS 100 X1VT | VENTS 100 X1VTH | VENTS 100 X1 L | VENTS 100 X1V L | VENTS 100 X1 K | VENTS 100 X1T K | VENTS 100 X1 K L | Measurement unit |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Voltage | 220-240 | V | ||||||||||
| Frequency | 50 | Hz | ||||||||||
| Power consumption | 14 | W | ||||||||||
| Air capacity | 99 | m³/h | ||||||||||
| Current | 0.085 | A | ||||||||||
| RPM | 2300 | min-1 | ||||||||||
| Sound pressure level at 3 m | 33 | dBА | ||||||||||
| Weight | 0.6 | kg | ||||||||||
| Spigot size | 100 | mm | ||||||||||
| Engine Type | 220-240V / 50Hz | - | ||||||||||
| Duct diameter | 100 | mm | ||||||||||
| Design | axial | - | ||||||||||
| IP Code | IP 24 | - | ||||||||||
| Type | exhaust | - | ||||||||||
| Mounting | wall mounting, ceiling mounting | - | ||||||||||
| Parameter | Value | Measurement unit |
|---|---|---|
| Ø D | 100 | mm |
| B | 152 | mm |
| H | 120 | mm |
| L | 108 | mm |
| L1 | 12 | mm |
